CRS Face Milling Cutter
Enlargement
| ⌀D | ⌀d | d* | R | H | Number of Flutes | 刀片Type No | 刀片螺絲 | 壓板 | 壓板螺絲 | 扳手 |
| 50 | 25.4 | 22 | 5 | 45 | 4 | APMT1604 | SCR-CAP4 | CL-5R | SCR-CRS3.5 | T15 |
| 63 | 25.4 | 22 | 5 | 50 | 5 | |||||
| 50 | - | 22 | 6 | 45 | 4 | RDMT1204MOTN | SCR-CRS4L | CL-6R | ||
| 60 | 25.4 | 22 | 6 | 50 | 5 | |||||
| 50 | - | 22 | 8 | 45 | 3 | APMT1604 | SCR-CRS5 | CL-8R | SCR-CRS5 | T20 |
| 60 | 25.4 | 22 | 8 | 50 | 3/4 | - | SCR-W1/4S | |||
| 66 | 25.4 | 27 | 8 | 50 | 4 | |||||
| 80 | 25.4 | 27 | 8 | 50 | 5 | |||||
| 100 | 31.75 | 32 | 8 | 55 | 5 | |||||
| 116 | 31.75 | 32 | 8 | 60 | 6 | CL-8R116H | SCR-CRS6 |
