    Product Name : Ultra Cobalt Ball Nose End Mill

    FEATURES:

    Suitable for milling round-bottom grooves and special profiles. The 2-flute design provides excellent chip evacuation during slotting.

    內角 Tool Diameter Shank Diameter Flute Length Overall Length
    0.5R 1.0 6 2.5 50
    0.75R 1.5 6 4 50
    1R 2.0 6 5 50
    1.25R 2.5 6 6 60
    1.5R 3.0 6 8 60
    2R 4.0 6 8 70
    2R 4.0 8 8 70
    2.5R 5.0 8 10 80
    2.5R 5.0 8 10 80
    3R 6.0 8 12 90
    3R 6.0 8 12 90
    3.5R 7.0 8 14 90
    4R 8.0 8 14 100
    4R 8.0 10 20 75
    4.5R 9.0 10 18 100
    5R 10.0 10 18 100
    5.5R 11.0 12 22 100
    6R 12.0 12 22 110
    6.5R 13.0 12 26 110
    7R 14.0 12 26 110
    7.5R 15.0 12 30 110
    8R 16.0 16 30 140
    8.5R 17.0 16 34 140
    9R 18.0 16 34 140
    9.5R 19.0 16 38 140
    10R 20.0 20 38 160
    12.5R 25.0 25 50 160

    m/m
