美制粗牙UNC
|
美制细牙UNF
|
|
规格
|
规格
|
规格
|
|
W 1/8-40
|
UNC 2 - 56
|
UNF 3 - 56
|
|
W 5/32-32
|
UNC 3 - 48
|
UNF 4 - 48
|
|
W 3/16-24
|
UNC 4 - 40
|
UNF 5 - 44
|
|
W 1/4-20
|
UNC 5 - 40
|
UNF 6 - 40
|
|
W 5/16-18
|
UNC 6 - 32
|
UNF 8 - 36
|
|
W 3/8-16
|
UNC 8 - 32
|
UNF 10 - 32
|
|
W 7/16-14
|
UNC 10 - 24
|
UNF 12 - 28
|
|
W 1/2-12
|
UNC 12 - 24
|
UNF 5/32 - 36
|
|
W 9/16-12
|
UNC 3/16 - 24
|
UNF 3/16 - 32
|
|
W 5/8-11
|
UNC 1/4 - 20
|
UNF 1/4 - 28
|
|
W 3/4-10
|
UNC 5/16 - 18
|
UNF 5/16 - 24
|
|
W 7/8-9
|
UNC 3/8 - 16
|
UNF 3/8 - 24
|
|
W 1"-8
|
UNC 7/16 - 14
|
UNF 7/16 - 20
|
|
W 1" 1/8 - 7
|
UNC 1/2 - 13
|
UNF 1/2 - 20
|
|
W 1" 1/4 - 7
|
UNC 9/16 - 12
|
UNF 9/16 - 18
|
|
W 1" 3/8 - 6
|
UNC 5/8 - 11
|
UNF 5/8 - 18
|
|
W 1" 1/2 - 6
|
UNC 3/4 - 10
|
UNF 3/4 - 16
|
|
W 1" 3/4 - 5
|
UNC 7/8 - 9
|
UNF 7/8 - 14
|
|
W 1" 7/8 - 4 1/2
|
UNC 1" - 8
|
UNF 1" - 12
|
|
W 2" - 4 1/2
|
UNC 1" 1/8 - 7
|
UNF 1" - 14
|
|
|
UNC 1" 1/4 - 7
|
UNF 1" 1/8 - 12
|
|
|
UNC 1" 1/2 - 6
|
UNF 1" 1/4 - 12
|
|
|
UNC 2" - 4 1/2
|
UNF 1" 1/2 - 12
|
|
|
|
UNF 2" - 12
|
